Specifications
Frame: 6061 Alloy Stealth Evo, hydroformed tubing, Updated Zero Suspension System, 150mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.
Sizes: S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm
Rear shock: Rockshox Deluxe Select+, 185x55mm, Trunnion top mount, 30x8mm bottom bushings
Shock settings: L compression, digressive rebound, 4 tokens
Fork: Rockshox Psylo Gold RC, 160mm, 3 Position, Debon Air, tapered steerer tube, Boost 15x110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload
Headset: Acros custom IS52/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs without blocklock
Stem: Onoff S3 30mm 0º, 6061 forged alloy, 31.8mm barbore
Handlebar: Onoff S3 1.0 6061 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 1.5 rise.
Grips: Onoff Forest, CNC lock-on, 135mm
Seatpost: Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 140-115mm (388-235mm), M size: 160-135mm (428-255mm), ML size: 180-155mm (468-275mm), L size: 210-185mm (528-305mm), XL size: 210-185mm (528-305mm)
Saddle: Fizik Terra Aidon X5 145mm
Front brake: Sram DB8 stealth, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
Rear brake: Sram DB8 stealth, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
Brake lever: Sram DB8, SwingLink and lever pivot bearings, tools-free reach and contact point adjust
Rims: Mavic E-CrossRide 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes
Spokes: Mavic J-bend double butted, contactless lacing
Front hub: Mavic, Boost 15x110mm, IS 6 bolts
Rear hub: Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, HG freehub
Front tire: Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX GRIP compound, EXO+ protection, 60TPI, folding bead
Rear tire: Maxxis Minion DHR II 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 60TPI, folding bead
Crankset: e*Thirteen Helix Core E*Spec Plus, All sizes: 160mm
Rings: Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD
Chain: Sram GX Eagle T-Type, 12s, Powerlock
Rear derailleur: Sram S1000 Eagle AXS T-Type, 12s
Shift levers: Sram Eagle AXS Pod MMX, 12s
Cassette: Sram XS-1270, 10-52T, T-Type, 12s
Weight: 20,9 kg
Display: Purion 400 / Bosch Mini Remote / Bosch System Controller
Motor: Bosch Performance Line SX (25Km/h) SMART SYSTEM Diagonal, Wide
Battery: Bosch Compact Powertube 400Wh
